| OS | Item | Feature | Description |
|---|
| Android 6.0 | Boot | Bootloader | RK3128MiniLoaderAll_V2.31.bin |
|---|
| Kernel | Version | Linux 3.10.0 |
| Drivers | HDMI | Support 1080P, 720P resolution |
| Audio | Audio out, MIC |
| SD card | Micro SD card |
| USB | 4x USB2.0 Host and 1x USB2.0 OTG |
| Ethernet | 10/100/1000 Mbit/s Ethernet |
| Camera | 5 Megapixels, OV5640 model |
| CVBS | Support 480i/576i resolution |
| Buttons | Recover, Power on/off (system) |
| Serial Port | 1x RS232 serial port for debugging |
| IR Remote control | Support IR Remote control |
| GPIOS | 1x 40Pin(2.0mm pitch) connector for GPIOS and power |
| Embedded GUI | Android6.0.1 | Support Alarm Clock, Browser, Gallery, Calculator, Camera, Email, ES File Explorer, video player, Music etc. |
| Cross-compiler Environment | VMware V7+ ubuntu-12.04, java-7-openjdk-amd64.tar.bz2 |
| Debug Tools | SecureCRT, AndroidTool.exe, ADB |
