| Specifications |
|---|
| SoC | Samsung ARM926EJS S3C2416 400MHz with separate 16KB instruction and 16KB data caches, 2D Accelerator |
| SDRAM | 128MB DDR2 SDRAM, 133MHz, 32bit |
| NAND Flash | 256MB or 1GB SLC NAND Flash |
| Serial Port | 3 serial ports, one for GPS, one for GPRS/CDMA, one for Debug |
| CDMA or GSM/GPRS | Support standard AT command Set |
| LCD | 4.3 inch LCD, resolution 480*272 |
| Key | 5 keys, one for power control |
| Audio codec | WM8976 Audio chip |
| ADC | Adjustable resistor is connected with pins of ADC to check analog/digital change |
| RTC | Real Time Clock, powered by external lithium battery |
| Printer | printing on 2-inch widepaper (58mm) print at 80 mm/s (640 dotlines/s), 8 dots/mm of resolution |
| Micro SD card | Support 1G, 2G, 3G card |
| power | 7.8V battery, supporting charge online |
| others | Vibrators, Speaker, microphone, headphone |
| Dimensions | 190 x 84 x 42 mm(Length*Width*Thickness) |
