| Specifications |
|---|
| SoC | - Rockchip RK3399. Big.Little architecture: Dual Cortex-A72 + Quad Cortex-A53, 64-bit CP
- 28nm HKMG process
- 1MB unified L2 Cache for Big cluster, 512KB unified L2 Cache for Little cluster |
| GPU | - ARM Mali-T860MP4 GPU, support OpenGL ES1.1/2.0/3.0/3.1/3.2, OpenCL1.2, DirectX11.1 etc
- Supports AFBC (ARM Frame Buffer Compression) |
| Memory | 4GB |
| Storage | - 32GB eMMC flas
- MicroSD slot |
| Power | 3.7V Li-Battery |
| USB | USB Type-C. USB OTG |
| Audio | Realtek ALC5651 Audio CODEC. 3.5mm audio jack |
| Display | - HDMI 2.0 for 4K@60Hz with HDCP 1.4/2.
- MIPI LCD |
| Connectivity | - 2.4GHz 802.11 b/g/n WiFi. Bluetooth 4.0 |
| UART | 1x 3pin connector for debug |
| Buttons | Power, Recover, Data_clear |
| GPS | Ublox 7 GPS Chipset |
| Camera | 1x MIPI CSI |
| Others | Gyroscope+G-sensor, LIGHT-Sensor, Compass |
