| Specifications |
|---|
| SoC | Rockchip RV1126B-P. Quad-core Cortex-A53 @ 1.6GHz |
| NPU | 3 TOPS |
| Memory | 2GB/4GB LPDDR4 |
| Storage | 8GB/16GB/32GB/64GB/128GB/256GB eMMC
MicroSD card slot |
| Power Supply | 12V/3A DC input jack
7.4V Lion Battery connector |
| USB | 1x USB OTG 2.0
4x USB Host 2.0 |
| Connectivity | Gigabit Ethernet RJ45 port via Realtek RTL8211F-CG controller
2.4G WiFi (802.11b/g/n) with Bluetooth 4.2 |
| Serial | 1x Serial port for debug, 3-pin connector
1x UART, 6-pin connector
1x RS485, 3-pin connector |
| Display | MIPI DSI, 26-pin header |
| Audio | Rockchip RK809 audio codec. 3.5mm Audio out jack
2-channel Speaker (4-pin connector)
1x digital MEMS MIC, 1x differential MIC |
| Camera(optional) | 2x MIPI Cameras, 24-pin FPC connector. |
| Keys | Recover, Power |
| Other features | RTC battery, GPIO, SPI, I2S, ADC, CAN, IR |
| Operating Temperature | 0° to + 70° C |
| Dimensions | Based board - 120 x 95 mm; CPU module - 38 x 30 mm |
