| Specifications |
|---|
| SoC | Rockchip RK3128. Quad-Core ARM Cortex-A7 32-bit SoC @ 1.2GHz |
| GPU | - Mali-400MP2 GPU, support OpenGL ES1.1/2.0
- High performance dedicated 2D processor |
| Memory | 1GB DDR3 |
| Storage | 4GB eMMC flash |
| Power | DC 5V/2A Power Adapter, or 3.7V Li-Battery |
| USB | USB3.0 Host |
| Audio | Realtek ALC5640 Audio CODEC.
1x MIC, 1x Speaker, 2x 3.5mm audio jack |
| Display | MIPI Panel, 25-pin FPC connector |
| Connectivity | - 2.4GHz 802.11b/g/n WiFi
- RFID |
| GPS | Ublox 7 GPS Chipset |
| UART | 1x 4pin connector for debug |
| Buttons | Power, Wake-up/VOL+, Recover/VOL- |
| Others | IR Transmitter, IR RECEIVE, Gyroscope+G-sensor, LP Sensor, Compass, Vibration |
| Dimensions | 150 x 57 mm |
